V.15
V.15
Full-range, passive two-way system
KTV specific voicing
Enhanced bass response from rear ports
LF driver with demodulating ring for distortion-free vocals
User-rotatable horn
Vertical and horizontal mounting option
Cloth-backed perforated steel grille
Trapezoid enclosure with textured finish
8Ω nominal impedance
Internal crossover network with LF and HF driver protection
Twin NL4 connectors
Multiple M8 rigging inserts
V.15
Cam kết chất lượng
Cam kết dịch vụ
Cam kết giá tốt
Model: V.15
Overview
With the new V·Series, Martin Audio engineers have designed a range of premium full-range loudspeakers specifically for small-medium scale entertainment installations and family KTV. Three, passive two-way systems — the V.10, V.12 and V.15 —combine the Martin Audio signature sound of warmth, clarity and smooth response with the vocal presence required for a great Karaoke experience.
Thông số kỹ thuật
| TYPE | High-power, passive two-way system |
| FREQUENCY RESPONSE (5) | 56Hz-20kHz ± 3dB -10dB @ 40Hz |
| DRIVER |
|
| RATED POWER (2) | 1000W program, 2000W peak |
| SENSITIVITY (8) | 100dB |
| MAXIMUM SPL (9) | 130dB program, 133dB peak |
| NOMINAL IMPEDANCE | 8Ω |
| DISPERSION (-6DB) | 80° H x 50° V (user-rotatable) |
| CROSSOVER | 2.3kHz passive |
| ENCLOSURE | Trapezoid |
| FINISH | Black textured paint |
| PROTECTIVE GRILLE | Black perforated steel with scrim cloth backing |
| CONNECTORS | 2 x NL4 type |
| PIN CONNECTIONS (INPUT) | 1+/1- |
| PIN CONNECTIONS (LINK) | 1+/- to 1+/- |
| FITTINGS | 10 x M8 inserts |
| DIMENSIONS |
|
| WEIGHT | 31kg (68.3lbs) |
