Model: TH153

Overview

A product of the TH Series, the TH153 3-way speaker includes a 15" speaker for bass, an 8" speaker for midrange and a 1" speaker for high frequencies. Waveguide and driver technology produce clear, engaging, and powerful sound. The TH153's unique combination of size, high performance and excellent sound makes it ideal for a wide range of uses. This speaker delivers on quality, response and sound level from a relatively compact source.

Thông số kỹ thuật

Driver: LF: 15" ; HF: 8" + 1"
Operating Band: LF: 28Hz - 250Hz ; HF: 250Hz - Up
Sensitivity: LF: 102dB/2.8V ; HF: 106dB/4V
Power (AES): LF: 400W ; HF: 250W
Nominal Impedance: LF: 8Ω ; HF: 12Ω
Usable Bandwidth (-3db): 60Hz - 18kHz
Nominal Dispersion: 50° Horizontal x 25° Vertical
Connectors: 2 x Neutrik NL4
